Specifications

Impact bar craddle

Under loading point

Designed exactly on demand

+++

+++

Any size required

6 m/s max

-10 to 50°C

3 to 11

Perfect fit & Strongest design

Type :

Position :

Technology :

Ease of installation:

Ease of maintenance:

Sizes available:

Speed:

Temperature range :

pH range :

Philosophy:

Technology

The idea :

​

Tailor made impact craddle designed, produced and shipped within few weeks

The result :

​

Stronger structure than adjustable ones (no weak point)

Perfect fit during installation (even adjustable system can't adapt to all situations)

Why is it better ?

Other solutions                                 vs                                      ATLAS

Idlers are spaced and limited absorbers

Impact bars are continuous and have high absorbing capacity

Not efficient sealing

Flat surface for top notch sealing

Because height and width are not adjustable, standard design would need anyway a lot of modification and adaptation during installation

Articulation = Weak points

More complexe =more expensive

Designed directly to fit the conveyor

No modification or adaptation needed

No Weak point

Design

Every single details on the ATLAS impact bed is produced with "Perfect" and "Strong" keywords in mind:

Please note the ATLAS impact bed, Shock absorbers, entyrance idler support and the SealBloc skirt are sold separately

Product range

Any dimensions available

- Lenght of 1200mm or 600mm

- Impact bar th. 50mm or 75mm

Designs

- Regular shape

- Transition shape (close to the tail drum)

- U-shape

- Adjustable (better avoir it, for light condition only)

- Any special design

Options

- Heavy duty shock absorber

- All or part made of stainless teel

​

Good to know

The combination of the  ATLAS  impact craddle and reinforced  SealBloc skirt  gives the loading point the best sealing and belt protection
