Polyvalent.



Specifications

Type :

Position :

Technology :

Ease of installation :

Ease of maintenance :

Sizes available :

Speed 1 way :

Speed 2 ways :

Temperature range :

pH range :

Philosophy:

Wear compensation multi-blade

Secondary cleaner

Patented dual-shore rubber

++

++

500 to 1400 belt (...2200 N-HD)

3 m/s max (5 m/s N-HD)

2,5 m/s max (3,5 m/s N-HD)

-10 to 50°C

4 to 10

Versatility and Cost effective



Technology

The idea :



Segment the scraper into several small ones each having their own structure, elasticity and adjustement

- Lower part made of impact and abrasion resitant rubber

- Higher part made of elastic rubber

The result :



The RacloFlex N can adapt any situation and usage with a high cleaning result

Due to its strong and specific design, the RacloFlex N is also very efficient on 2 ways belts

Designed by TechnicGum in Belgium

Produced and assembled in European Union

Get the Job done!



Why is it better ?

Other belt cleaners                               vs                                 RacloFlex N

Wear Gap due to lack of adjustment

No Gap

Rubber bloc size - Quantity of elastomer (±15g) versus competitors

55g

160g

290g

245g

980g

335g

RacloFlex N

The structure is exposed to severe condition in the most dirty place of the conveyor

The structure is perfectly protected to ensure a long lifetime



Design

Every single details on the RacloFlex N have been developed with "Inexpensive" and "Polyvalent keywords in mind



Product range

Blade

- Wear resistant Tungsten carbide : 1750 Hv / 93 HRA 3x10mm (5x10/N-(HD)

- Impact resistant carbide : 900 Hv / 66 HRA 5x10mm

- Wear & chemical resistant Ceramic : 1200 Hv / 75 HRA 7x10mm

- Food grade Stainless steel: 180 Hv / 15 HRA - 5x20mm

Design

- Standard design sent in short time

- Heavy Duty Design 1400-2200mm belt : RacloFlex N-HD

- Special quality rubber bloc (ex: oil resistant)

- Any special

Options

- All or part stainless steel

- Pulling pressure

- Multitool Key

Good to know

Installing jointly the  RacloFlex  and the  RacloFlex NT  is an easy way obtain the best cleaning solution available
